Oil Particle Counter HM-Y10

The oil particle counter is a device specifically designed for rapid detection of oil contamination levels in laboratories or on site, using the light blocking counting principle specified by the International Hydraulic Standards Committee. It has the advantages of small size, light weight, fast detection speed, high accuracy, and low cost. Built in micro water sensor and temperature sensor, which can detect both water content and oil temperature while detecting pollution level. Suitable for transformer oil (i.e. insulation oil), hydraulic oil, lubricating oil, synthetic oil and other fluids, it can be widely used in aerospace, petrochemicals, transportation ports, steel metallurgy, automobile manufacturing and other fields.

Main Features

Using the principle of photoresist (shading) method and high-precision laser sensor, it has small size, high accuracy, and stable performance

Suitable for laboratory or on-site testing, it can be connected to an external pressure chamber to form positive/negative pressure, enabling the detection and degassing of high viscosity samples

Built in data analysis system, capable of displaying real data of particle size in each channel and automatically determining sample grade

The pipeline is made of 316L and PTFE materials to meet the testing requirements of various organic solvents and oils

Equipped with volume flushing and duration flushing modes, convenient for users to use and maintain the equipment

Built in particle pollution level standards such as ISO4406, NAS1638, SAE4059 (integral and differential), GJB420A, GJB420A, Г OCT17216, GB/T14039, etc

Built in calibration function, can calibrate according to standards such as GB/T21540, ISO4402, GB/T18854, etc

Built in data analysis system, capable of automatically determining levels based on standards, with automatic data processing and printing functions

Built in micro water sensor and temperature sensor

Bilingual in Chinese and English, one click switch, with preset, parameter modification, and storage functions, easy and fast operation

Ultra large storage, can be stored inside the instrument or on external storage devices

Embedded design, high-strength casing, easy to carry, suitable for various types of construction machinery

Technical Specifications

Light source: semiconductor laser

Offline detection speed: 5-60mL/min (factory default 25ml/min)

Offline detection of sample viscosity: ≤ 100cSt (pressure chamber can be selected for high viscosity)

Particle size range: 1-500 μ m

Interface: USB interface, power interface

Data storage: Provides 1000 sets of data storage space and supports USB storage

Sensitivity: 1 μ m or 4 μ m (c)

Limit coincidence error: 40000 particles/ml

Counting volume: 1-999ml (recommended 10 or 20ml)

Counting accuracy: error less than ± 10%

Protection level: IP67

Test interval: 1-24 hours

Test sample temperature: 0-80 ℃

Water activity reference value: 0-1aw

Water content: 0-360ppm

Working temperature: -20-60 ℃

Screen: 4.3 inches

Power supply: AC 220V ± 10%, 50/60Hz or DC12-40V

Weight: 2.5kg

Volume: 275 × 220 × 107mm
